C60 Mobile Computer (Android 10)

Go Further for Powerful Performance

Chainway C60 is a lightweight, high-performance, rugged mobile computer for enterprises. C60 is based on Android 10, adopting Qualcomm high-performance processor and high-capacity removable battery with high-end configuration. The computer can integrate functions such as barcodes, NFC, front and rear cameras, etc. The device can be implemented in a wide range of industries, including logistics, warehousing, retail, and asset management, helping clients significantly bring their operations and management to the next level.

C60 Mobile Computer (Android 10)

Go Further for Powerful Performance

Features

Android 10	Qualcomm Octa-core 1.8 GHz
RAM+ROM: 3+32GB/4+64GB (optional)	4350mAh Removable Battery

Functions

Barcode Scanning (Optional)	NFC
13MP Autofocus Camera	Dual-band WIFI

Specifications

Physical Characteristics

Dimensions	159.5 x 65.7 x 16.8 mm / 6.28 x 2.58 x 0.66 in.
Weight	219 g / 7.72 oz. (device with battery)
Display	4-inch (18:9), TFT α-Si 1080 x 540
Battery	4350 mAh removable main battery Standby: up to 490 hours (only main battery ; WiFi: up to 470h; 4G: up to 440h) Continuous use: over 12 hours (depending on user environment) Charging time: 2.5 hours (charge device by standard adaptor and USB cable)
Touch Panel	Multi-touch panel, gloves and wet hands supported
Notification	Sound, LED indicator, vibrator
Interfaces	USB Type-C, USB 2.0, OTG
Card slot	1 slot for Nano SIM card, 1 slot for Nano SIM or TF card
Audio	2 microphones，1 for noise cancellation；1 speaker；receiver
Keypad	5 side keys : power, 2 scan keys, volume +/- Main keyboard: 22 keys (numeric keys, direction key, screen-lock key, Enter, Del, F1-F10, etc.)
Sensors	Accelerometer sensor, light sensor, proximity sensor, gyroscope

Communication

WLAN	Support 802.11 a/b/g/n/ac/d/e/h/i/k/r/v, 2.4G/5G dual-band, IPV4, IPV6, 5G PA; Fast roaming: PMKID caching, 802.11r, OKC Operating Channels: 2.4G(channel 1~13), 5G(channel36,40,44,48,52,56,60,64,100,104,108,112,116,120,124,128,132, 136,140,144,149,153,157,161,165),Depends on local regulations Security and Encryption: WEP,WPA/WPA2-PSK(TKIP and AES),WAPI-PSK—EAP-TTLS,EAP-TLS, PEAP-MSCHAPv2, PEAP-LTS,PEAP-GTC,etc.
WWAN	2G: 850/900/1800/1900 MHz 3G: CDMA EVDO: BC0, BC1 WCDMA: B1/B2/B4/B5/B8 TD-SCDMA: A/F(B34/B39) 4G: B1/B2/B3/B4/B5/B7/B8/B12/B13/B17/B20/B28/B38/B39/B40/B41
Bluetooth	Bluetooth 4.2/4.1+HS/4.0/3.0+HS/2.1+EDR
Vo-LTE	Support Vo-LTE HD video voice call
GNSS	GPS/AGPS, GLONASS, BeiDou,Galileo,internal antenna

Developing Environment

Operating System	Android 10.0; Soti MobiControl, SafeUEM supported
SDK	Chainway Software Development Kit
Language	Java
Tool	Eclipse / Android Studio

Performance

CPU	Qualcomm 1.8GHz Octa-core
RAM+ROM	3GB+32GB / 4GB+64GB (optional)
Expansion	Supports up to 128 GB Micro SD card

User Environment

Operating Temp.	-20 ℃~+50 ℃
Storage Temp.	-40 ℃~+70 ℃
Humidity	5% RH – 95% RH non condensing
Drop Specification	Multiple 1.5 m / 4.92 ft. drops to the concrete across the operating temperature range
Tumble Specification	1000 x 0.5 m/1.64 ft falls at room temperature
Sealing	IP65 per IEC sealing specifications
ESD	±15 KV air discharge, ±8 KV conductive discharge

Barcode Scanning

2D Scanner	Zebra: SE4710; Honeywell: N6603; DS7000, IA166S, IA171S
1D Symbologies	UPC/EAN, Code128, Code39, Code93, Code11, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI, RSS, etc.
2D Symbologies	PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode; Postal Codes: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal (KIX),etc.
